MMR X-Bolt 140 10

Motor Performance Line CX Smart System with up to 340% pedal assistance and maximum torque of 85Nm for a unique experience on technical and demanding climbs. Limits are there to be broken. Our new X-BOLT 2024 is more energetic, more capable and raises the bar even higher to take you places you've never been before. Robust and agile even on the most technical trails.
Combined with its integrated Bosch PowerTube battery, 625Wh, compact and lighter, which can be optionally supplemented with the Bosch 250Wh extender. Internal cable routing with entry to the frame at the front of the down tube. 140mm fork travel, as well as rear shock. 4-bar rear suspension with a pivot point on the chainstays that ensures great sensitivity and independence from braking and acceleration forces.

Tech spec

• Frame: X-Bolt - G2 Carbon Concept Frame. Intermediate modulus carbon fiber. Several molds. TA 12mm. Internal Cable Routing. Boost. Post Mount. Full Integrated Battery. Head tube 1.5 Tapered
• Fork: Fox Factory 36 E-Bike 29 140mm
• Shock absorber: Fox Float Factory E-Bike 140 Trunnion
• Gear shifter: Shimano XT M8100 SGS 12V
• Buttons: Shimano XT M8100 12V
• Brakes: Shimano XT M8120 203/180
• Cranks: FSA KFX Ultralight 34T
• Cassette: Shimano Deore M6100 10/51 12V
• Chain: Shimano Deore M6100 12V
• Wheels: DT Swiss H1900 Hybrid 35 Boost CL MS
• Tyres: Hutchinson Griffus 29 2.50 TL SideSkin
• Crankset: Race Face Ride 35
• Handlebar: Race Face Turbine R35 800mm
• Seat post: Fox Transfer Factory 125mm
• Saddle: San Marco GND Dynamic
• Motor: Bosch Performance Line CX Smart System
• Battery: Bosch Power Tube 625
• Display: Bosch Kiox 300

Producer's notes: depending on component availability, specifications are subject to change without notice. Images are for illustrative purposes only.
