Mondraker Dusty X

From sacrifice to asphalt

The Dusty X Unlimited Gulf Edition is based on our Dusty RX model with targeted and specific upgrades added to the construction. The carbon fiber handlebar comes from the ONOFF S9 range and comes with silicone grips, Mavic supplies the Cosmic SL carbon wheels with a 45 mm profile, and SRAM supplies the Force AXS drivetrain complete with carbon fiber cranks.

Tech spec

• Frame: Dusty Stealth Air Carbon, Press-fit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated non-removable internal battery, 12x142 mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.
• Sizes: S: 440 mm / M: 460 mm / L: 500 mm / XL: 530 mm
• Fork: Stealth Air Carbon tapered head tube, HHG, integrated fork with Flat Mount flat mount support
• Steering: Onoff IS52/IS52, 1-1/8“, 1.5” head tube, sealed bearings, internal cable routing.
• Stem: Onoff Semi-Integrated, 31.8mm bar bore, rise: -7°, length: S size: 60mm, M size: 70mm, L size: 80mm, XL size: 90mm
• Handlebar: OnOff S9 Urban Carbon rise: 0mm, width: 640mm, 9º backsweep, 0º upsweep, 31.8mm bore
• Grips: Onoff Foam lightweight 135mm
• Seatpost: Seatpost with integrated Supernova LED rear light, diameter 27.2mm, length 400mm
• Saddle: FIZIK Vento Argo X5 140mm
• Front brake: Sram Level Silver 2P Stealth, 2-piece caliper, Centerline 160 mm one-piece brake disc with 6 IS bolts, organic pads with steel backing
• Rear brake: Sram Level Silver 2P Stealth, 2-piece caliper, Centerline 160 mm one-piece brake disc with 6 IS bolts, organic pads with steel backing
• Brake levers: Sram Level Silver, tool-free reach adjustment, lever swivel bearings
• Rims: Mavic Cosmic SL 45, UST, 45mm height, 23mm internal width, hookless, 24 spokes front, 28 spokes rear
• Spokes: Mavic Steel double butted flat spokes
• Front hub axle: Mavic, 12x100mm, IS 6 bolts
• Rear hub axle: Mahle X20 drive unit, XDR freehub
• Front tire: Maxxis Re-fuse 700x40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead
• Rear tire: Maxxis Re-fuse 700x40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead
• Cranks: SRAM Force 1 Carbon Wide, S: 170mm, M: 170mm, L: 172.5mm, XL: 175mm.
• Crankset: Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide
• Bottom bracket: Mahle DUB Press Fit, sealed bearings, sensor w/ torque
• Chain: Sram Rival, 12s, Powerlock
• Rear derailleur: Sram Force XPLR Etap AXS, 12s
• Shifters: Sram Eagle AXS Pod, 12s
• Cassette: Sram XG-1271, 10-44T, 12s
• Dropout: Mondraker M076
• Front light: 150LUX CC 6-12V output
• Cage: waterproof alloy
• Display: Pulsar One Wireless

Producer's notes: depending on component availability, specifications are subject to change without notice. Images are for illustrative purposes only.
